Zohd Vc400 Camera System For Fpv Rc

ZOHD VC400-CP AIO 5.8GHz 400mW Camera System for FPV RC Airplane

Features

• 3-in-1 AIO integrated design, with a camera, VTx, and antenna, ultra-lightweight and small size, the best solution for light-weight airplanes.
• With OSD to show Power-on time and Input Voltage, so you can know how long you can keep flying.
• Default JST plug and up to 25cm power cable, longer enough for most small size airplanes.
• Up to 2.5km video transmission range on 400mW.
• Wide voltage input from 7-28V, safe for all kinds of battery or BEC input.
• With customized ve1cro strap to hold the camera and EVA foam for anti-vibration.
• Switchable between 0.1mW / 25mW / 200mW / 400mW.
• Optional Clover / Dipole antenna for different airframes and flight mode (for straight-line flights or flying around).
• 8Ghz VTx with 40 racing channels.
• Allows you to display customized Call Signs.
• The power cable was soldering and fixed by silica glue, solid even in a crash.

Specifications

• Input voltage: 7-28V
• Frequency band: 5.8GHZ
• Video format: NTSC
• Camera resolution: 600TVL
• Antenna connector: Clover / Dipole
• Field of View: 120 degrees
• Size: 24*15*10mm
• Weight: 8g
• Output power: 0.1mW / 25mW / 200mW / 400mW
• Operating current: 90mA (0.1mW) 150mA (25mW) 270mA (200mW) 360mA (400mW)
• Product Weight: 8g
• Product Size(L x W x H): 24 x 15 x 10mm
