Traxxas Slash 4X4 Vxl 1/10Scale 4Wd White & Red 68086-4

LENGTH:

23.36 INCHES (568 MM)

FRONT TRACK:

11.65 INCHES (296 MM)

REAR TRACK:

11.65 INCHES (296 MM)

CENTER GROUND CLEARANCE:

2.83 INCHES (72 MM)

WEIGHT:

93.1 OUNCES (2.64 KG)

HEIGHT (OVERALL):

7.60 INCHES (193 MM)

WHEELBASE:

12.75 INCHES (324 MM)

SHOCK LENGTH:

LONG (FRONT), XXLONG (REAR)

TIRES:

TRAXXAS 2.2 INCH PRE-GLUED WITH FOAM INSERTS

TIRE DIAMETER:

4.31 INCHES (109.5 MM) (FRONT AND REAR)

WHEELS (FRONT/REAR):

2.2 INCH SPLIT-SPOKE, BLACK OR RED BEADLOCK

WHEEL DIAMETER:

2.2 INCHES (56 MM) OUTER
3.0 INCHES (76 MM) INNER

SPEED CONTROL TYPE:

VXL-3S™ ELECTRONIC SPEED CONTROL

MOTOR (ELECTRIC):

VELINEON® 3500 BRUSHLESS

OVERALL DRIVE RATIO:

11.82 (STOCK, OUT-OF-BOX)

DIFFERENTIAL TYPE:

HARDENED STEEL BEVEL, SEALED, LIMITED SLIP

GEAR PITCH:

32

CHASSIS STRUCTURE/MATERIAL:

MOLDED TUB / NYLON COMPOSITE

DRIVE SYSTEM:

SHAFT-DRIVEN, DIRECT DRIVE 4WD

STEERING:

DUAL-BELLCRANK WITH INTEGRATED SERVO SAVER

RADIO SYSTEM (TRANSMITTER)

­

TQI™ 2.4GHZ (2-CHANNEL)

RADIO SYSTEM (RECEIVER)

­

TRAXXAS STABILITY MANAGEMENT™ (#6533)

TOP SPEED:

60+MPH*

SKILL LEVEL:

1

BATTERY TRAY DIMENSIONS:**

165 MM X 49.5 MM X 23 MM, 25 MM

REQUIRED ITEMS:

NIMH OR LIPO BATTERY, CHARGER, 4 "AA" BATTERIES (FOR TRANSMITTER)
