KYOSHO AIRIUM EDGE540 VE29 PIP

700mm Size Super Scale Flying Model EDGE540 VE29 readyset

■Length: 600mm
■Width: 700mm
■Weight: 320g（with 800mAh LiPO）
■Motor: AF400 BLS B/07/15 brushless motor
■Battery: Team Orion AVIONICS 800 7.4V(30C) LiPO battery
■Wing Area: 8.3dm2
■Wing Load: 38.6g/dm2
■Wing Type: NACA0014（symmetry）
■R/C System: 4ch 3 servo 1 ESC R/C system
■Propeller: D7 x P6
■Side/Down Thrust: 0 / 0°
■Flight Time: 9 minutes（with 800mAh LiPO）

Readyset Contents

●Factory assembled airplne
●AF400 BLS B/07/15 brushless motor
●Sky Victory BLS10（ESC）
●KT-21 transmitter
●KR-21 receiver
●KS-21 servo x 3

●DC balance charger for AF LiPO
●Spare propeller
●Spare spinner
●Spanner for removing propeller
●Philipp driver

＜ Required for Operation ＞
●AA sized alkaline battery x 8

• Team Orion AVIONICS 800 7.4V(30C) LiPO battery
