JP Hobby Mantis 150A HV ESC 6-12S OPTO
SKU 04170
Sold out
Original price
₹ 36,450.00
-
Original price
₹ 36,450.00
Original price
₹ 36,450.00
₹ 36,450.00
-
₹ 36,450.00
Current price
₹ 36,450.00
JP Hobby Mantis 150A HV ESC 6-12S OPTO
DATA SHEET
|
Sizes: |
48 mm x 80 mm x 21 mm |
|
Weight (gr): |
142 gr |
|
Max Intensity (A): |
150A |
|
SBEC (A) |
OPTO no BEC |
|
Battery Cells: |
6s - 22.2v, 7s - 21.77v, 8s - 29.6v, 9s - 33.3v, 10s - 37v, 12s - 44.4v |
|
Connection: |
Delivered without plug |
|
Battery Cells Compatibility: |
8-38 NC / 6-12 LiPo |
JP Hobby Mantis 150A HV ESC 6-12S OPTO
The JP Hobby 150 Amp Brushless Electronic Speed Controller is using a firmware specificaly designated to be used with JP Hobby pole counts motors.
A High Power 12S capable system for RC Airplanes and Helicopters.
Features
- Super smooth and accurate throttle linearity
- Programmable: Done by Transmitter
- Safety thermal over-load protection
- Auto throttle shut down in signal lose situation
- Low Voltage Cut off
- Governor Mode
- Over-heat protection: When the temperature of ESC exceeds 110 deg C, the ESC will reduce the output power to allow it too cool.
- Lost signal protection: The ESC will automatically cut power to the motor when it detects a lost of throttle signal for 2 seconds, then the motor will emit continuous beeping tone.
Specifications
- Continous Current: 150A
- Burst Current: 180A
- Battery: 6-12S Lipo
- Weight: 142g
- BEC Output: No BEC. OPTO.
- Size: 48mm x 80mm x 21mm
